| TECHNICAL SPECIFICATIONS |
PARAMETER |
| Power Supply Voltage |
AC 220V |
| Air Source Pressure |
≥бbar |
| Conveying Length |
1600mm(customizable) |
| Conveying Width |
720mm(customizable) |
| Atomization Pressure |
Manually control 0-6bar |
| Opening Pressure |
Manually control 0-6bar |
| Conveying System |
0.4KW |
▲Application: Applicable to toast pans, circular pans, rectangular pans, flat pans, and other various molds, etc.
▲Installation: The factory provides independent air source connector with G4 screw; inner diameter of air hose≥19mm; stable air pressure, 6kg; power supply, 220V & 380V.
▲Accuracy: Delta servo conveyor ensures accurate position when spraying to avoid waste of release oil.
▲Filter & Pressure Regulator: Equipped with Airtac filter and pressure reducing valve, and you could control atomization and opening pressure by manually, to ensure the spraying effect.
▲Specialized Sprayer Gun: Use the Haidi Tiantu SEADROPS specialized sprayer gun in blue color, with an effective atomization diameter reaching between 3cm to 12cm, ensuring the demolding effect.
▲Cost Control: Suitable for medium and low viscosity release oil; improves the utilization rate of release oil to control cost.
▲Spray Gun Design: The Design of a single-row spray gun needs to adjust the position of the spray gun by manually positioning it accurately against the mold hole. SIEMENS support saving 4 groups of mold parameters for easy operation.
▲Applicable to: Choose appropriate release agents according to the texture of the dough.
